Hughes 9450L-C11 Lite BGAN: Mobile Satellite Terminal

Hughes 9450L-C11 Lite BGAN: Mobile Satellite Terminal

Using the world’s smallest mobile BGAN terminal from Hughes, customers can connect at IP broadband speeds of up to 464 kbps while on-the-move.

Model Number: 3500497-0015

The Hughes 9450L-C11 terminal is fully approved for operation on Inmarsat’s Broadband Global Area Network (BGAN) satellite service and provides high-performance, on-the-move connectivity for the most demanding environments.

The Hughes 9450L-C11 is a low cost, highly competitive mobile terminal, ideal for government, first responders, public safety, mobile healthcare, and remote mobile fleet personnel in industries, such as utility, oil and gas, forestry, cable, and telecommunications.

Corporate disaster planners and remote field personnel can collaborate reliably and efficiently with various agencies and headquarters staff.

The Hughes 9450L-C11 terminal is IP-based and offers selectable, dedicated Quality of Service (QoS) levels.

Simple, quick, and flexible options are available for installation on any vehicle. The mini-antenna may be permanently mounted for fleet-style installation or the optional magnetic roof mount can be used for rapid installation and removal.

The Hughes 9450L-C11 terminal has four (4) Ethernet ports, which allow the user to connect multiple devices.

Download Product Sheet

  • Features and Benefits
  • Technical Information
  • In the Box

Features and Benefits

Fully autonomous tracking antenna acquires and tracks the BGAN satellite signal while on-the-move or on-the-pause
Four Ethernet ports supporting multiple devices
Internal Web User Interface (UI) for configuration and control without the use of LaunchPad
Auto context activation feature allows data connections to be activated without user action

4.6 x 28.1 x 23.4 cm

2.3 Kg

25.2 x 11.9 cm

2.0 Kg

IP56 antenna

Up to 464 kbps shared

-25°C to +55°C

95% RH at +40°C

12V or 24v systems

Up to 128kbps


In the Box

Hughes 9450 Mobile Satellite Terminal
Installation manual
Tracking antenna incl. 8m RF cable & power cable
User manual
Hughes 9450L-C11 Lite BGAN: Mobile Satellite Terminal
Hughes 9450L-C11 Lite BGAN: Mobile Satellite Terminal

Contact us today for more information.
