Intellian Fleet One Antenna System

Intellian Fleet One antenna system for Inmarsat Fleet One Services offers simultaneous voice and data maritime connectivity up to 150 Kbps. Comes as a standalone variant.

Model Number: F4-A100-S

Intellian Fleet One Antenna System uses the now standard Intellian AptusLX for easy configuration – common to all the latest generation Intellian antennas.

Features and Benefits
Technical Information
In the Box

Features and Benefits

Voice – 1 Voice Line

Simultaneous voice and data

Standard IP – Up to 150 kbps

Built-in firewall

2 LAN ports, with PoE

soft PABX

Wi-Fi

Single coaxial cable connection between ADU and BDU combines power and control signals through a single cable up to 100m.

Certification for FCC, RED, KC and TELEC.

Technical Information

Dimensions

ADU: 29.5 x Ø 29.1CM BDU: 28 x 19 x 4.1CM

Input Voltage

10.8 ~ 30 V DC

Standard Data Rate

UP: up to 150 Kbps Down: up to 150 Kbps

Operating Temperature

ADU: -25°C to +55°C BDU: -15°C to +55°C

IP Rating

ADU: IP56 BDU: IP31

Call Features Voice

Broadband

Data

In the Box

Above Deck Unit

10m Coaxial Cable

ADU Bolt Kit

ADU Mounting Template Below Deck Unit

Quick Install Guide (User Manual in Web UI)

1m Ethernet Cable

1m DC Power Cable

Terminal Block (For inter-connection of DC Power cables)

Wi-Fi Antenna

BDU Bolt Kit

Additional items for 19" rack mount version:

AC/DC adapter (150W)

ACU power cable (EU)

ACU power cable (US)

Rack conversion bracket
